ELS 5 Specs
CORE SPECS
PEM Water Electrolysis
Use Solar and Wind Power to Produce Hydrogen Power. You Don't Need a Grid.
Thermal Recovery System
Option to Provide Electricity and Heat Together.
Current
Nominal: -550 to +250A
Voltage
Nominal: 48VDC, Single Phase
Dimensions & Weight
1333 mm X 563 mm X 1758 mm [L X W X H] <850 KG
FEATURES
Start & Shutdown Time
Cold start time: < 5min
Hot start time:< 1min
Shutdown time: < 5min
Certification
CE conformity Assessment and manufacturer Declaration of compliance.
- Pressure Equipment Directive (2014/68/EU) Compliant
- Low Voltage Directive (2014/35/EU) Compliant
LIFETIME
Duration
> 8000 Cycles
~ 15 Years
Water supply (If off-Grid)*
Standard residential potable water
Consumption:< 0.5 L/Hr normal
FACILITY
Installation
Temperature: 2°C to 50°C
Humidity: 0 % to 95% RH non condensing
Max altitude: 2000 M
Pollution degree 3 [IEC 60664-1]
off-Grid*: If off-grid power supply is required for the facility, we will equip the corresponding electrolyzer to generate hydrogen for storage in our system.
Activate Green Power!
Exportable Logs
Software automatically generates and exports power generation reports for easy monitoring.
Low Noise
Quiet operation ensures minimal disturbance, ideal for residential and sensitive environments.
Easy Maintenance
Runs on minimal tap water—no manual refueling, reducing labor and transport costs.
Zero Emissions
Clean energy production with no harmful pollutants, supporting sustainability.
Charge
Charge Power: 8.85 KW
Efficiency: 75%
Discharge
Discharge Power: 10 KW
Capacity
Conventional Capacity: 50 KWH (Configurable)
POWER INTERFACE
